product details

The InfiniiVision 2000 X-Series offers entry-level price points
to fit your budget with superior performance and optional
capabilities that are not available in any other oscilloscope in its
class. This Keysight Technologies, Inc. breakthrough technology
delivers more scope for the same budget.

Powered by Froala Editor

product details

The EDU36311A triple-output power supply has a compact design to fit anywhere on your bench. Monitor all your outputs simultaneously from any angle with its 7-inch color display. Each output is independent — connect your outputs in a series for higher voltage, in parallel for additional current, or stack to provide 0 to ±30 V. A sequencing feature enables and disables outputs in a set pattern. You can now activate the control logic before applying power to the rest of your device.

Powered by Froala Editor

product details

SPA3000 Digital Power Meter has multiple measurement channels and wide current range which can measure voltage, current and power consumption of the measured devices with high power and precision. The semi-rack design makes it suitable for power consumption test bench and automated assembly line testing. In addition, the device is equipped with a multi-channel D/A output and extensive I/O ports, allowing technicians to adopt the solution to the specific application.

Powered by Froala Editor

product details

The Keysight DAQM907A module Data Acquisition System allows great flexibility for a variety of sense and control applications. It combines two 8-bit ports of digital input and output, a 100 kHz gated totalizer, and two ±12V analog outputs - all on a single earth-referenced module. The analog outputs have two additional voltage/current sensing channels. The digital inputs and totalizer input may be included in a scan. Alarm limits for the digital and event counter inputs are evaluated continuously, capturing and logging alarm conditions even between scans.

Digital Input/Output
Use the digital outputs with an external power supply to control microwave switches and attenuators, solenoids, power relays, indicators, and more. Use the digital inputs to sense limit switch and digital bus status. There are no complex handshake modes; reads and writes are initiated either from the front panel or the bus.

Totalize Input
Count events from devices like photo interrupters, limit switches, and Hall-effect sensors.
It keeps an updated total which can be read via the front panel or programmatically at any time. With 26 bits of resolution, it can count events at full speed for nearly 45 minutes without an overflow.

Analog Output
Use the two electronically calibrated analog outputs to source bias voltages to your device under test, to control your analog programmable power supplies, or use the outputs as setpoints for your control systems. The outputs are programmed directly in volts, either from the front panel or from the bus.
