KT1886B Multi-function Safety Tester
KT1886B Multi-function Safety Tester

KT1886B Multi-function Safety Tester

THB 300,000.00

quantity
add to cart
SKU: KT1886B
Brand: SPS Electronic
share it

KT 1886B is a combined test device for electrical safety & function test with 19 test types.  This tester has integrated safety current limitation at DC & AC Voltage.  It is equipped with built-in full electronic source for function test with high-precision & fast measurement technology.

Powered by Froala Editor

  • 10.1” TFT Color Display
  • USB (x2), RS 232, Ethernet/LAN, CAN
  • digital input (x8), digital output (x8), analog input (x2), analog output
  • Integrated storage with 4 GB (optional expandable to 64 GB) makes it possible to save almost unlimited test plans and test results
  • Continuity test 24 VDC / 600 mA
  • Short circuit test 24 VDC / > 600 mA
  • Earth bond test (AC) 1 A up to 30 A, No-load 6 V or 12 V, Resistance max. 10 Ohm
  • Insulation measurement 100 VDC up to 6000 VDC, up to 1 GOhm (voltage-dependent)
  • High voltage test (DC) 100 V – 6000 V, 0 – 10 mA
  • High voltage test (AC) 100 V – 5500 V, 0 – 3 mA
  • Leakage current test 50 – 270 VAC (potential free), Short circuit current ≤ 10 mAAC
