S1801M Multi-Function Safety Tester

Details
Specification

S 1801M tester is perfectly suitable for fast, cost effective and standard-compliant safety testing that meets nearly all current international standards. It is perfectly usable for a manual workplace as well as for routine & series testing in production. This tester has integrated safety current limitation at DC & AC Voltage.

4.3” TFT-Color-display
USB (x2), RS 232, Ethernet/LAN, digital input (x8), digital output (x8)
Wide range mains supply from 90 V till 250 V (50 Hz and 60 Hz)
Ground bond Test 1 – 30 AAC; 0 – 400 mOhm
Insulation Resistance Test 100 – 6000 VDC; 0,25 MOhm – 1 GOhm
High Voltage Test (AC) 100 – 5500 V; 0 – 3 mA
High Voltage Test (DC) 100 – 6000 V; 0 – 10 mA
Safety current limited according EN 50191
Read input steps, set output step, read analog input step & set analog output step
Integration of inputs and outputs in the testing process makes it possible to integrate mechanical assemblies and switching matrix without additional installation
