Keysight E36154A

Details
Specification

E36154A 800W AThe Keysight E36154A is an 800W, 30V, 80A Autoranging Benchtop single power output DC power supply. The E36154A includes advanced characterization tools such as data logging, an optional scope view, and arbitrary waveform generation. This enables in-depth analysis and precise output modulation for power simulation applications, allowing you to accelerate development projects without compromising quality. All these features work together to provide a one-box solution that eliminates the typical requirements of multiple instruments, therefore, helping you to save time without complex setups as well as reducing your test costs.utoranging Benchtop Power Supply, 30V, 80A

Output Rating- 800 W

Output 1: 0 to 30 V, 0 to 80 A

Programming Accuracy ± (% of output + offset)

Voltage: 0.03% + 5 mV
Current: 0.1% + 20 mA

Ripple & Noise (20 Hz to 10 MHz)

Normal mode Voltage: <50 mV p-p
Normal-mode Voltage: <5 mV rms

Readback Accuracy ± (% of output + offset)

Voltage: 0.03% + 5 mV
Current: 0.1% + 20 mA
Low Range Current: 0.1% + 250 uA
