| SKU: | 34465A |
| Brand: | Keysight |
Keysight 34465A & 34470A DMMs offer unprecedented levels of accuracy, speed and resolution. They can measure very low current down to a 1 μA range, enabling their use on very low power devices. The ability to auto-calibrate during the measurement allows the 34465A and 34470A to maintain a calibrated measurement while the instrument may be going through temperature drift/changes. Graphical capabilities, including trend charts and histograms, facilitate greater user insight gained more quickly. Both DMM models provide a data logging mode for easier trend analysis and a digitizing mode for capturing transients. Instrument upgrade options (available separately) includes: 3446MEMU ( 867-2284 ) which extends memory to 2 million readings. Buyers of upgrades receive an entitlement certificate, register via Keysight website and obtain a software keycode to enable the upgrade.
Powered by Froala Editor
Resolutions up to 6.5 digits (34465A) and 7.5 digits (34470A)
Reading rates up to 5000 readings/s standard (50,000 with optional upgrade3446DIGU)
Memory up to 50,000 readings standard (2 million with optional upgrade 3446MEMU)
Voltage ranges from 100 mV to 1000 V
Current ranges from 1 μA to 10 A
USB and LAN interfaces
BenchVue software purchased separately
