| SKU: | RL42 |
| Brand: | SPS Electronic |
Electromechanical relays for practical and robust application in system and switch cabinet
manufacture. Monostable DC relay with proven technology and almost unlimited life.
Powered by Froala Editor
Contacts: double pole double throw
Field coil: Coil voltage 24 V DC (5 – 55 °C) / Coil current 0.20 A (20 °C) / Inrush current(first 100 ms)0.25 A
Coil resistance: 115 Ω (20 °C)
Status indication: LED
Connections: Switching circuits flat plug 6.3 mm (0.25 in.) / Field Coil flat plug 4.8 mm (0.19 in.)
Switching capacity: max. 5,000 VA (ohmic load)
Test Voltage: Contact/field coil 20,000 V DC / Contact set 11 & contact set 21 8,000 V DC
Switching voltage Max: 6,000 V AC
Switching current: max. 10 A AC
Continuous current: max. 30 A AC / DC
Transition resistance: < 30 mΩ
Switching frequency: max. 3 / s
Mechanical switching cycles: > 1 x 106
Vibration resistance: 10 – 55 Hz/g 5
Shock strength: g – 11ms 5
Carrier material: PBT GF30
Protection system: IP 20
General data: Dimensions (HxWxD) and weight:55 x 78 x 48 mm (approx. 300 g) / Storag e& Operation temp. -25 up to +40 °C / +5 up to +55 °C
Fastening: Top rail (via Mounting Clip)
Accessories: Mounting Clip MC 22, Contact Protection DK 21
